PC30F8

PC30F8 ,the fast recovery diode module,has four unique features: The first one is isolated base. The second one is dula diode Arms-cathode common. The third one is ultra-fast recovery. The last one is high surge capability.

There are some maximum ratings about PC30F8. Repetitive peak reverse voltage per Arm(VRRM) is 800 V. Non-repetitive peak reverse voltage per Arm(VRSM) is 880 V.RMS forward current(IF(RMS)) is 47 A per Arm. Peak one-cycle forward surge current(IFSM) is 450 A(50 Hz half sine wave, non-rpetitive per Arm). I square t(I2t) is 1000 A2s(2 ms to 10 ms per Arm). Operating frequancy(f) is 20 KHz. Operating junction temperature range is -40 to 150. Storage temperature range is -40 to 125.Isolation voltage(Viso) is 2000 V(base plate to terminal,AC i1min).Otherwise, there are also some electrical and thermal characteristics about it. Peak forward voltage(VFM) is 2.5 V max when IFM is 30 A , Tj is 25 per Arm. Peak reverse current(IRM) is 2 mA max when VRM is VRRM and Tj is 150 pe Arm. Reverse recovery time(trr) is 60 ns max when IFM is 10 A, -di/dt is 50 A/us, Tj is 25 per Arm. Thermal resistance is 0.8/W max(junction to case per Arm) or is 0.1/E(case to fin with thermal compound). Internal lead inductance(Ls) is 30 nH max (anode terminal to cathode terminal pe element).

Well, this is a simple introduction to this type of product, if you want to know more about PC30F8, please pay more attention to our web. Thanks for your attention!
