PA44

Features: ·SURFACE MOUNT PACKAGE·MONOLITHIC MOS TECHNOLOGY·LOW COST·HIGH VOLTAGE OPERATION-350·LOW QUIESCENT CURRENT-2m·NO SECOND BREAKDOWN·HIGH OUTPUT CURRENT-120 mA PEAApplication·TELEPHONE RING GENERATOR·PIEZO ELECTRIC POSITIONING·ELECTROSTATIC TRANSDUCER & DEFLECTION·DEFORMABLE MIRROR FOCU...

product image

PA44 Picture
See larger image
SeekIC No. : 004453869 Detail

PA44: Features: ·SURFACE MOUNT PACKAGE·MONOLITHIC MOS TECHNOLOGY·LOW COST·HIGH VOLTAGE OPERATION-350·LOW QUIESCENT CURRENT-2m·NO SECOND BREAKDOWN·HIGH OUTPUT CURRENT-120 mA PEAApplication·TELEPHONE RING G...

PA44 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
PA44
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

·SURFACE MOUNT PACKAGE
·MONOLITHIC MOS TECHNOLOGY
·LOW COST
·HIGH VOLTAGE OPERATION-350
·LOW QUIESCENT CURRENT-2m
·NO SECOND BREAKDOWN
·HIGH OUTPUT CURRENT-120 mA PEA


Application

·TELEPHONE RING GENERATOR
·PIEZO ELECTRIC POSITIONING
·ELECTROSTATIC TRANSDUCER & DEFLECTION
·DEFORMABLE MIRROR FOCUSING


Specifications

SUPPLY VOLTAGE, +VS to VS 350V
OUTPUT CURRENT, continuous within SOA 60mA
POWER DISSIPATION, continuous @ TC = 25 120mW
INPUT VOLTAGE, differential 12W
INPUT VOLTAGE, common mode ±16V
TEMPERATURE, pin solder 10 sec ±V S
TEMPERATURE, junction2 220
TEMPERATURE, storage 150
TEMPERATURE RANGE, powered (case) 65 to 150
40 to 125



Description

The PA44 is a high voltage monolithic MOSFET operational amplifier achieving performance features previously found only in hybrid designs while increasing reliability. Inputs of PA44 are protected from excessive common mode and differential mode voltages. The safe operating area (SOA) PA44 has no second breakdown limitations and can be observed with all type loads by choosing an appropriate current limiting resistor. External compensation of PA44 provides the user flexibility in choosing optimum gain and bandwidth for the application.

The PA44 is packaged in Apex's PSOP1 non-hermetic surface mountable dual in line package. The metal back of the package is tied to-Vs.
