PA43__07

Features: · Electrically Isolated Heatsinking· Compression Bonded Elements· Metal Baseplate· Low Thermal Impedance for Improved Current CapabilityApplication· Transfer Switches· AC Welders· Motor Soft StartersSpecifications Characteristics Conditions Symbol Units Repetitive ...

product image

PA43__07 Picture
See larger image
SeekIC No. : 004453868 Detail

PA43__07: Features: · Electrically Isolated Heatsinking· Compression Bonded Elements· Metal Baseplate· Low Thermal Impedance for Improved Current CapabilityApplication· Transfer Switches· AC Welders· Motor So...

PA43__07 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
PA43__07
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

· Electrically Isolated Heatsinking
· Compression Bonded Elements
· Metal Baseplate
· Low Thermal Impedance for Improved Current Capability


Application

· Transfer Switches
· AC Welders
· Motor Soft Starters


Specifications

Characteristics
Conditions
Symbol
Units
Repetitive Peak Forward and Reverse Blocking
Voltage
VDRM & VRRM
1800
V
Non-Repetitive Peak Blocking Voltage
(t < 5 msec)
VRSM
1900
V
RMS Current
(AC Switch, 180 o Conduction
180onduction, Tc=74
180onduction, Tc=78
180onduction, Tc=82
180onduction, Tc=86
IT(RMS)
IT(RMS)
IT(RMS)
IT(RMS)
1775
1665
1550
1440
A
A
A
A
Average Forward Current Per SCR
(180 o Conduction)
180onduction, Tc=74
180onduction, Tc=78
180onduction, Tc=82
180onduction, Tc=86
IT(AV)
IT(AV)
IT(AV)
IT(AV)
800
750
700
650
A
A
A
A
Peak One Cycle Surge Current, Non-Repetitive
Tj = 25C, Vr = 0
60 Hz
50 Hz
ITSM
ITSM
69,000
63,000
A
A
Peak One Cycle Surge Current, Non-Repetitive
Tj = 25C, Vr = Vrrm
60 Hz
50 Hz
ITSM
ITSM
46,000
42,000
A
A
Peak One Cycle Surge Current, Non-Repetitive
Tj = 125C, Vr = 0
60 Hz
50 Hz
ITSM
ITSM
60,000
54,750
A
A
Peak One Cycle Surge Current, Non-Repetitive
Tj = 125C, Vr = Vrrm
60 Hz
50 Hz
ITSM
ITSM
40,000
36,500
A
A
Peak Three Cycle Surge Current, Non-Repetitive
60 Hz, Tj = 125C, Vr = Vrrm
ITSM
32,100
A
Peak Ten Cycle Surge Current, Non-Repetitive
60 Hz, Tj = 125C, Vr = Vrrm
ITSM
25200
A
I2t for Fusing for One Cycle
Tj = 125C, Vr = Vrrm
8.3 milliseconds
10 milliseconds
I2t
I2t
6.60 x 10 6
6.66 x 10 6
A2 sec
A2 sec
Maximum Rate-of-Rise of On-State Current,
(Non-Repetitive)
Per JEDEC Standard 397 5.2.2.6
di/dt
400
A/s
Maximum Rate-of-Rise of On-State Current,
(Repetitive)
Per JEDEC Standard 397 5.2.2.6
di/dt
150
A/s
Operating Temperature
TJ
-40 to +125
Storage Temperature
Tstg
-40 to +150
Max. Mounting Torque, M6 Mounting Screw
132
15
in. Lb.
Nm
Max. Mounting Torque, M10 Terminal Screw
106
12
in. Lb.
Nm
Module Weight, Typical
455
11.75
g
lb
V Isolation @ 25C
Vrms
3000
V



Description

Powerex AC Switch SCR Modules are designed for use in applications of PA43__07 requiring phase control and isolated packaging. The modules are isolated for easy mounting with other components on a common heatsink.
