Product Details

Description



Features:

• LOW COST
• WIDE COMMON MODE RANGE - Includes negative supply
• WIDE SUPPLY VOLTAGE RANGE
    Single supply: 5V to 40V
    Split supplies: ±2.5V to ±20V
• HIGH EFFICIENCY - |Vs2.2V| at 2.5A typ
• HIGH OUTPUT CURRENT - 2.5A min
• INTERNAL CURRENT LIMIT
• LOW DISTORTION


Application

• HALF & FULL BRIDGE MOTOR DRIVERS
• AUDIO POWER AMPLIFIER
    STEREO - 18W RMS per channel
    BRIDGE - 36W RMS per package
• IDEAL FOR SINGLE SUPPLY SYSTEMS
    5V - Peripherals
    12V - Automotive
    28V - Avionic


Specifications

SUPPLY VOLTAGE, total 5V to 40V
OUTPUT CURRENT SOA
POWER DISSIPATION, internal (per amplifi er) 25W
INPUT VOLTAGE, differential ±VS
INPUT VOLTAGE, common mode +VS, -VS.5V
JUNCTION TEMPERATURE, max1 150
TEMPERATURE, pin solder-10 sec max 300
TEMPERATURE RANGE, storage 65 to 150
OPERATING TEMPERATURE RANGE, case 55 to 125



Description

The PA34 consist of a monolithic power op amp in a 7-pin T0220 package.

The wide common mode input range of PA34 includes the negative rail, facilitating single supply applications. It is possible to have a "ground based" input driving a single supply  amplifi er with ground acting as the "second" or "bottom" supply of the amplifi er.

The output stage of PA34 is also well protected. They possess internal current limit circuits. While the device is well protected, the Safe Operating Area (SOA) curve must be observed. Proper heatsinking is required for maximum reliability.

The tab of the 7 pin plastic package is tied to VS.
