P2040A

Features: ·FCC approved method of EMI attenuation.·Provides up to 20dB of EMI suppression.·Generates a low EMI spread spectrum clock of the input frequency.·Input frequency range: 30MHz to 100MHz.·Optimized for VGA, SVGA, and higher resolution XGA LCD Panels.·Internal loop filter minimizes externa...

product image

P2040A Picture
See larger image
SeekIC No. : 004439076 Detail

P2040A: Features: ·FCC approved method of EMI attenuation.·Provides up to 20dB of EMI suppression.·Generates a low EMI spread spectrum clock of the input frequency.·Input frequency range: 30MHz to 100MHz.·O...

P2040A Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
P2040A
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/25

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

·FCC approved method of EMI attenuation.
·Provides up to 20dB of EMI suppression.
·Generates a low EMI spread spectrum clock of the input frequency.
·Input frequency range: 30MHz to 100MHz.
·Optimized for VGA, SVGA, and higher resolution XGA LCD Panels.
·Internal loop filter minimizes external components and board space.
·Six selectable high spread ranges up to ± 2%.
·Two selectable modulation rates.
·SSON# control pin for spread spectrum enable and disable options.
·Low cycle-to-cycle jitter.
·Wide operating range.
·Low power CMOS design.
·Supports most mobile graphic accelerator specifications.
·Products available for automotive temperature range. (Refer Spread Spectrum Range Selection Tables)
·Available in 8-pin SOIC and TSSOP Packages.


Application

The P2040A is targeted towards digital flat panel applications for notebook PCs, palm-size PCs, office automation equipments and LCD monitors.




Pinout

Connection Diagram


Specifications

Symbol
Parameter
Rating
Unit
VDD,VIN
 Voltage on any pin with respect to GND
-0.5 to + 7.0
V
TSTG
 Storage temperature
-65 to +125
°C
TC
 Operating temperature-Commercial
0 to 70
°C
TA
 Operating temperature
-40 to +125
°C
TJ
 Junction Temperature
150
°C
TDV
 Static Discharge Voltage
(As per JEDEC STD22- A114-B)
2
KV
Note: These are stress ratings only and are not implied for functional use. Exposure to absolute maximum ratings for prolonged periods of time may affect device reliability.


Description

The P2040A is a versatile spread spectrum frequency modulator designed specifically for digital flat panel applications. The P2040A reduces electromagnetic interference (EMI) at the clock source, allowing system wide reduction of EMI of down stream clock and data dependent signals. The P2040A allows significant system cost savings by reducing the number of circuit board layers ferrite beads, shielding and other passive components that are traditionally required to pass EMI regulations.

The P2040A uses the most efficient and optimized modulation profile approved by the FCC and is implemented in a proprietary all digital method.

The P2040A modulates the output of a single PLL in order to "spread" the bandwidth of a synthesized clock,and more importantly, decreases the peak amplitudes of its harmonics. This results in significantly lower system EMI compared to the typical narrow band signal produced by oscillators and most frequency generators. Lowering EMI by increasing a signal's bandwidth is called 'spread spectrum clock generation'.
