P172

Features:

` Low-profile, 8-lead mini-DIL or gull-wing style package:
- Suitable for SONET/SDH applications
` Metal package:
- Offers superior shielding for high noise immunity
` Planar structure for high reliability
` Operating wavelength range:
- 1.25 m-1.6m
` Available in 8 mm core single-mode fiber or 62.5 m core multimode fiber pigtails
` Wide operating temperature range:
- APD/PIN, 40 to +85
` Scheduled to be qualified according to Telcordia Technologies ™ GR-468-CORE
` Typical sensitivity:
- APD, 32 dBm
- PIN, 23 dBm
` Thermistor in APD version


Application

· Long-reach or metro SONET OC-48 and SDH STM-16, or multidata-rate telecommunications applications
· SONET/SDH receivers and transponders
·Line terminal equipment


Specifications

Parameter	Symbol	Min	Max	Unit
Positive Supply Voltage	VCC	0.5	4.0	V
Optical Input Power: APD PIN	PIN PIN	- -	0 8.0	dBm dBm
Operating Case Temperature Range: APD/PIN	TC	40	85
Storage Temperature Range	Tstg	40	85
Lead Soldering Temperature	-	-	250
Lead Soldering Time	-	-	10	s

Description

The P172-type receiver consists of a PIN or APD coupled to a single-mode or multimode fiber pigtail and a linear preamplifier. Both the PIN and APD are rear-illuminated planar diode structures with a low-capacitance active area for maximum responsivity and speed.

This P172 incorporates the new Laser 2000 manufacturing process from the Optoelectronics Products unit of Agere Systems Inc. Laser 2000 is a low-cost platform that targets high-volume manufacturing and tight product distributions on all optical subassemblies. This platform of P172 incorporates an advanced optical design that is produced on Agere Systems' highly automated production lines. The Laser 2000 platform of P172 is qualified for central office and uncontrolled environments, and can be used for applications requiring high performance and low cost.
