P111

The P100 series of integrated power circuits consists of power thyristors and power diodes configured in a single package.The P111 belongs to P100 series.

Features of the P111 are:(1)glass passivated juncrions for greater reliability;(2)electrically isolated base plate;(3)available up to 1200VVRRM,VDRM;(4)high dynamic characteristics;(5)wide choice of circuit configurations;(6)simplified mechanical design and assembly;(7)UL E78996 approved.

The major ratings of the P111 can be summarized as:(1):the parameter is ID,the rating is 25,the units is A;(2):the parameter is ID @TC,the rating is 85,the units is ;(3):the parameter is IFSM @50Hz,the rating is 357,the units is A;(4):the parameter is IFSM @60Hz,the rating is 375,the units is A;(5):the parameter is I2t @50Hz,the rating is 637,the units is A2s;(6):the parameter is I2t @60Hz,the rating is 580,the units is A2s;(7):the parameter is I2t,the rating is 6365,the units is A2s;(8):the parameter is VRRMrange,the rating is 400 to 1200,the units is V;(9):the parameter is VINS,the rating is 2500,the units is V;(10):the parameter is TJ,the rating is -40 to 125,the units is .
