Features: `ULTRA LOW OFFSET VOLTAGE: 10V`ULTRA LOW DRIFT: ±0.1V/ `HIGH OPEN-LOOP GAIN: 134dB `HIGH COMMON-MODE REJECTION: 140dB `HIGH POWER SUPPLY REJECTION: 130dB `LOW BIAS CURRENT: 1nA max`WIDE SUPPLY RANGE: ±2V to ±18V`LOW QUIESCENT CURRENT: 800A/amp `SINGLE, DUAL, AND QUAD VERSIONS `REPLACES O...
OPA4277: Features: `ULTRA LOW OFFSET VOLTAGE: 10V`ULTRA LOW DRIFT: ±0.1V/ `HIGH OPEN-LOOP GAIN: 134dB `HIGH COMMON-MODE REJECTION: 140dB `HIGH POWER SUPPLY REJECTION: 130dB `LOW BIAS CURRENT: 1nA max`WIDE SU...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Supply Voltage..................................................................................36V
Input Voltage.....................................................(V-) -0.7V to (V+) +0.7V
Output Short-Circuit(2)..........................................................Continuous
Operating Temperature..................................................-55 to +125
Storage Temperature.....................................................-55 to +125
Junction Temperature.....................................................................150
Lead Temperature (soldering, 10s)................................................300
NOTE: (1) Stresses above these rating may cause permanent damage. Exposure to absolute maximum conditions for extended periods may degrade device reliability. (2) Short-circuit to ground, one amplifier per package.
The OPA277 series precision op amps replace the industry standard OP-177. They offer improved noise, wider output voltage swing, and are twice as fast with half the quiescent current. Features include ultra low offset voltage and drift, low bias current, high common-mode rejection, and high power supply rejection. Single, dual, and quad versions have identical specifications for maximum design flexibility.
OPA277 series op amps operate from ±2V to ±18V supplies with excellent performance. Unlike most op amps which are specified at only one supply voltage, the OPA277 series is specified for real-world applications; a single limit ap- plies over the ±5V to ±15V supply range. High performance is maintained as the amplifiers swing to their specified limits.
Because the initial offset voltage (±20V max) is so low, user adjustment is usually not required. However, the single version (OPA277) provides external trim pins for special applications.
OPA277 op amps are easy to use and free from phase inversion and overload problems found in some other op amps. They are stable in unity gain and provide excellent dynamic behavior over a wide range of load conditions. Dual and quad versions feature completely independent circuitry for lowest crosstalk and freedom from interaction, even when overdriven or over- loaded.
Single (OPA277) and dual (OPA2277) versions are available in 8-pin DIP and SO-8 surface-mount packages. The quad (OPA4277) comes in 14-pin DIP and SO-14 surface-mount -40 to +85 and packages. All are fully specified from operate from -50 to +125.
