OM7604ST

Features:

• Isolated Hermetic Package, JEDEC TO-257AA Outline
• Reference Voltages Set To ±2% (±1% Available)
• Built-In Thermal Overload Protection
• Short Circuit Current Limiting
• Product Is Available Screened To MIL-STD-883
• Similar To Industry Standard P/N LM150A


Specifications

Input Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +35V
Operating Junction Temperature Range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . -55°C to +150°C
Storage Temperature Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .-65° to +150°C
Typical Power/Thermal Characteristics:
Rated Power @ 25°C
T_C . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25W
T_A. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3W
Thermal Resistance
q_JC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4.2°C/W
q_JA. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42°C/W


Description

These OM7604ST are supplied in a hermetically sealed metal package whose outline is similar to the industry standard TO-220 plastic package. All protective features are designed into the circuit, including thermal shutdown, current limiting and safe-area control. With heat sinking, they can deliver over 3.0 amps of output current. These OM7604STs feature 2% initial voltage tolerance, 0.3% load regulation and 0.01% line regulation.
