OHB900: Industrial Hall Effect / Magnetic Sensors HALL EFFECT SENSOR
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Operational Type : | Unipolar | Operating Supply Voltage : | 25 V |
Current Rating : | 7 mA | Package / Case : | 3 PCB Pins |
Output Fall Time : | 1 uS | Mounting Style : | Screw |
Maximum Operating Temperature : | + 150 C | Minimum Operating Temperature : | - 40 C |
Maximum Output Current : | 25 mA |
The OHB900 contains of a hall effect sensor similar to the OH180U and a rare earth magnet mounted in a low cost plastic housing.The magnet produces optimum magnetic flux at hall effect sensor location.
Features of the OHB900 are:(1)operates over a board range of supply voltages;(2)excellent temperature stability;(3)non-contact motion sensing;(4)hall element,linear amplifier,and schmitt trigger on single hallogic silicon chip;(5)performs in high dust and dirt environements;(6)0.125"(3.18mm) wide gap.
The absolute maximum ratings of the OHB900 can be summarized as:(1):the parameter is supply voltage,the symbol is Vcc,the rating is 25,the unit is V;(2):the parameter is storage temperature range,the symbol is Ts,the rating is -55 to +160,the unit is ;(3):the parameter is operating temperature range,the symbol is TA,the rating is -50 to +150,the unit is ;(4):the parameter is lead soldering temperature [1/8 inch (3.2mm) from case for 5 sec. with soldering iron],the symbol is Ts,the rating is 260,the unit is ;(5):the parameter is output ON current,the symbol is ISINK,the rating is 25,the unit is mA;(6):the parameter is output OFF voltage,the symbol is Vout,the rating is 25,the unit is V;(7):the parameter is magnetic flux density,the symbol is B,the rating is unlimited.
Technical/Catalog Information | OHB900 |
Vendor | TT Electronics/Optek Technology |
Category | Sensors, Transducers |
Type | Hall Effect |
Output Type | Digital |
Voltage - Supply | 4.5 V ~ 24 V |
Package / Case | Slotted Body |
Frequency | 200kHz |
Termination Style | PC Pin |
Actuator Material | Ferrous Metals, Gear Tooth |
Lead Free Status | Lead Free |
RoHS Status | RoHS Compliant |
Other Names | OHB900 OHB900 365 1002 ND 3651002ND 365-1002 |
