OCP-PCT218/E: OPTOCOUPLER 2-CH TRANS OUT 8DIP

OCP-PCT218/E Data Sheet

US $ .25~.25 / Piece | Get Latest Price

Part Number:: OCP-PCT218/E
Mfg:
Supply Ability:: 5000

Price Break

Qty
0~60000

Unit Price
$.25

Processing time
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/12/22

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

OCP-PCP116 evaluate
US $.39 - .39 / Piece

OPTOCOUPLER DIGITAL OUTPUT 6-DIP
OCP-PCP116-TR evaluate
US $.36 - .36 / Piece

Logic Output Optocouplers Digital DC Open SMD-6 5000Vrms
OCP-PCT114/C evaluate
US $.07 - .07 / Piece

Transistor Output Optocouplers Photocoupler 1.2Vf 200mW, 200-400 CTR

Product Details

Quick Details

Series:	-	Manufacturer:	Lumex Opto/Components Inc
Number of Channels:	2	Input Type:	DC
Voltage - Isolation:	5000Vrms	Current Transfer Ratio (Min):	60% @ 2mA
Current Transfer Ratio (Max):	600% @ 2mA	Voltage - Output:	60V
Package / Case :	LLP-40	Current - Output / Channel:	50mA
Current - DC Forward (If):	50mA	Vce Saturation (Max):	300mV
Output Type:	Transistor	Mounting Type:	Through Hole
Package / Case:	8-DIP (0.300", 7.62mm)

Description

Series: -
Input Type: DC
Voltage - Isolation: 5000Vrms
Current - Output / Channel: 50mA
Output Type: Transistor
Current - DC Forward (If): 50mA
Vce Saturation (Max): 300mV
Number of Channels: 2
Mounting Type: Through Hole
Packaging: Tube
Package / Case: 8-DIP (0.300", 7.62mm)
Voltage - Output: 60V
Manufacturer: Lumex Opto/Components Inc
Current Transfer Ratio (Min): 60% @ 2mA
Current Transfer Ratio (Max): 600% @ 2mA

Parameters:

Technical/Catalog Information	OCP-PCT218/E
Vendor	Lumex Opto/Components Inc
Category	Isolators
Isolation Voltage	5000Vrms
Input Type	DC
Output Type	Transistor
Current - Output/Channel	50mA
Voltage - Output	60V
Vce Saturation (Max)	300mV
Current Transfer Ratio (Min)	60% @ 2mA
Mounting Type	Through Hole
Package / Case	8-DIP
Packaging	Tube
Number of Circuits	2 - Dual
Lead Free Status	Contains Lead
RoHS Status	RoHS Non-Compliant
Other Names	OCP PCT218 E OCPPCT218E 67 1561 5 ND 6715615ND 67-1561-5
