NTE1539

The NTE1539 is a multifunctional integrated circuit which is based on the internal circuit of the NTE1538. NTE1539 incorporates various functions required for  ynchronization and deflection circuits of color television sets and especially aims at increasing the detections accuracy of the Xray protection circuit. The ground pins for horizontal and vertical are provided separately to enable the easy layoutNof the printed circuit board. The NTE1539 differs from the NTE1538 in the following points:
` The output circuit of synchronizing separation is emitter follower type
` The Xray protection circuit is differential dual inouts thyristor system
` The ground pins for horizontal and vertical are provided separately.
