NJW1180

Features: ·Operating Voltage 8 to 13 V ·SRS WOW (including SRS 3D, FOCUS and TruBass function) ·Simulated Stereo ·4ch Input Selector ·Volume 0 to -80dB (0.5dB/step), MUTE ·Balance 0 to -30dB (1dB/step), MUTE ·Tone Control -15dB to +15dB(1dB/step) ·I2C BUS Interface ·Bi-CMOS Technology ·Package Out...

product image

NJW1180 Picture
See larger image
SeekIC No. : 004434652 Detail

NJW1180: Features: ·Operating Voltage 8 to 13 V ·SRS WOW (including SRS 3D, FOCUS and TruBass function) ·Simulated Stereo ·4ch Input Selector ·Volume 0 to -80dB (0.5dB/step), MUTE ·Balance 0 to -30dB (1dB/st...

NJW1180 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
NJW1180
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/1/8

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

·Operating Voltage 8 to 13 V
·SRS WOW (including SRS 3D, FOCUS and TruBass function)
·Simulated Stereo
·4ch Input Selector
·Volume  0 to -80dB (0.5dB/step), MUTE
·Balance  0 to -30dB (1dB/step), MUTE
·Tone Control   -15dB to +15dB(1dB/step)
·I2C BUS Interface
·Bi-CMOS Technology
·Package Outline QFP48-P1






Pinout

Connection Diagram


Specifications

Parameter Symbol Rating Units
Power Supply Voltage V+ 15 V
Power Dissipation PD 1500(note) mW
Operating Temperature Range Topr -40 to +85 °C
Storage Temperature Tstg -40 to +125 °C
(Note) At on a board of EIA/JEDEC specification. (76.2 ×114.3 ×1.6mm Two layers, FR-4)


Description

The NJW1180 is an audio processor with SRS WOW. It includes  all of functions processing audio signal for TV, such as volume,  balance, tone control and 4ch input selector. All of internal status  and variables are controlled by I2C BUS.
