Product Details

Description



Features:

·Operating Voltage 7.5 to 13V
·3ch Output(Lch, Rch, Subwoofer ch) / 2ch Output(Lch, Rch)
·4ch Input Selector
·LPF Filter (Adjustable cut off frequency by external parts)
·AGC Circuit (It reduces volume difference among input sources.)
·Adjustable AGC compression level by I2C BUS
·eala(NJRC Original Surround System)
·Simulated Stereo
·Voice Enhancement System
·I2C BUS Interface
·Bi-CMOS Technology
·Package Outline SDIP42


Pinout

Connection Diagram


Specifications

Parameter Symbol Rating Units
Power Supply Voltage V+ 15 V
Power Dissipation PD 700 W
Operating Temperature Range Topr -20 to +75 °C
Storage Temperature Tstg -40 to +125 °C



Description

The NJW1168 is a sound processor with subwoofer output includes all of functions processing audio signal for TV, such as input selector, tone control, balance, volume, mute, and AGC functions.

Also the NJW1168 includes the LPF for subwoofer output and bass boost function.

The eala of NJW1168 reproduces a natural surround sound with clear vocal orientation. And also, voice enhancement gives clear sound such as dialogs.

All of internal status and variables of NJW1168 are controlled by I2C BUS interface.
