NJW1157

Features: ·Operating Voltage ·Three-Wired Serial Data Control ·Input Selector (x 12) ·REC Output (x 5) with Selector ·Input Selector Gain Control ·Volume Output Gain Control·Volume ·Tone Control ·Subwoofer output addition to L, R channel output ·Subwoofer output ON/OFF control ·Bi-CMOS Technology ...

product image

NJW1157 Picture
See larger image
SeekIC No. : 004434635 Detail

NJW1157: Features: ·Operating Voltage ·Three-Wired Serial Data Control ·Input Selector (x 12) ·REC Output (x 5) with Selector ·Input Selector Gain Control ·Volume Output Gain Control·Volume ·Tone Control ·Su...

NJW1157 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
NJW1157
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/1/8

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

·Operating Voltage
·Three-Wired Serial Data Control
·Input Selector (x 12)
·REC Output (x 5) with Selector
·Input Selector Gain Control
·Volume Output Gain Control
·Volume
·Tone Control
·Subwoofer output addition to L, R channel output
·Subwoofer output ON/OFF control
·Bi-CMOS Technology
·Package Outline


Pinout

Connection Diagram


Specifications

Parameter Symbol Rating Units
Power Supply Voltage V+/V- +7.5/-7.5 V
Maximum Input Voltage VIM V+/V- V
Power Dissipation PD 700 mW
Operating Temperature Range Topr -20 to +75 °C
Storage Temperature Tstg -40 to +125 °C



Description

NJW1157 is an eight channel electronic volume IC.  NJW1157 includes Input selector, tone control, volume, mute,  input selector gain control, volume output gain control  and 5 REC  outputs. It's suitable for multi-channel  audio  equipments such as AV receivers and DVD  receivers. These functions are controlled by  three-wired serial data.
