NJM2706

Features: · Operating Voltage +4.7V to +13.0V· Wide Dynamic Range 3.1Vrms typ.· Low Output Noise 8.9µVrms typ.· eala 3D Surround Function (Stereo only)· Dynamic Bass Boost Function· High Frequency Compensation (f=10kHz, GV=+3dB)· Variable Surround Effect by external resistor· Internal Mode...

product image

NJM2706 Picture
See larger image
SeekIC No. : 004434100 Detail

NJM2706: Features: · Operating Voltage +4.7V to +13.0V· Wide Dynamic Range 3.1Vrms typ.· Low Output Noise 8.9µVrms typ.· eala 3D Surround Function (Stereo only)· Dynamic Bass Boost Function· High Fre...

NJM2706 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
NJM2706
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/1/8

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

· Operating Voltage +4.7V to +13.0V
· Wide Dynamic Range 3.1Vrms typ.
· Low Output Noise 8.9µVrms typ.
· "eala" 3D Surround Function (Stereo only)
· Dynamic Bass Boost Function
· High Frequency Compensation (f=10kHz, GV=+3dB)
· Variable Surround Effect by external resistor
· Internal Mode Control Switch
· Bipolar Technology
· Package Outline DMP24, SSOP24


Pinout

Connection Diagram


Specifications

PARAMETER SYMBOL RATINGS UNIT
Supply Voltage V+ 15 V
Power Dissipation PD (DMP24) 700
(SSOP24) 600		 mW
Operating Temperature Range Topr -20 to +855 °C
Storage Temperature Range Tstg -40 to +125 °C



Description

The NJM2706 is the 3D surround audio processor with dynamic bass boost, regenerates rich sound field with only small two speakers.

The NJM2706 performs NJRC original surround technology realizing natural surround sound field regarded centerorientation and NJRC original dynamic bass boost technology provides graceful bass sound with low distortion.

NJM2706 is suitable for mini-component, CD radio-cassette, TV, speaker system and others.
