NJM2192AL

Features: ·Operating Voltage 4.7 to 13V·Punch Control·Internal Bass Gain Control Switch·Bypass Function (Through)·Internal Mode Switch·External Adjustment for Speaker Size (Small, Medium, Large)·Bipolar Technology·Package Outline SDIP30, SDMP30PinoutSpecifications PARAMETER SYMBOL RATINGS ...

product image

NJM2192AL Picture
See larger image
SeekIC No. : 004433933 Detail

NJM2192AL: Features: ·Operating Voltage 4.7 to 13V·Punch Control·Internal Bass Gain Control Switch·Bypass Function (Through)·Internal Mode Switch·External Adjustment for Speaker Size (Small, Medium, Large)·Bip...

NJM2192AL Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
NJM2192AL
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/1/8

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

·Operating Voltage 4.7 to 13V
·Punch Control
·Internal Bass Gain Control Switch
·Bypass Function (Through)
·Internal Mode Switch
·External Adjustment for Speaker Size (Small, Medium, Large)
·Bipolar Technology
·Package Outline SDIP30, SDMP30


Pinout

Connection Diagram


Specifications

PARAMETER SYMBOL RATINGS UNIT
Supply Voltage V+ 15 V
Power Dissipation PD 700 mW
Operating Temperature Range Topr −40 to + 85 °C
Storage Temperature Range Tstg −40 to + 125 °C

<table width="4


Description

The NJM2192A is a Bass Enhancement Processor, based on SRS TruBass technology.

The NJM2192A eliminates the need for large speakers to create low frequency fundamental tones, and it enhances and complements subwoofer performance.

The NJM2192A is suitable for audio applications which are speaker system for mini components, CD radio cassette, multimedia speaker systems, TV and others.
