NCP1571

Maximum ratings are those values beyond which device damage can occur. Maximum ratings applied to the device are individual stress limit
values (not normal operating conditions) and are not valid simultaneously. If these limits are exceeded, device functional operation is not implied,
damage may occur and reliability may be affected.
1. 60 second maximum above 183°C.

The NCP1571 is a low voltage buck controller. It provides the control for a DC−DC power solution producing an output voltage as low as 0.980 V over a wide current range. The NCP1571−based solution is powered from 12 V with the output derived from a 2−7 V supply. It contains all required circuitry for a synchronous NFET buck regulator using the V2 control method to achieve the fastest possible transient response and best overall regulation. NCP1571 operates at a fixed internal 200 kHz frequency and is packaged in an SOIC−8.

This device provides undervoltage lockout protection, Soft−Start, Power Good with delay, and built−in adaptive non−overlap. During undervoltage lockout, the NCP1571 controller allows the power supply output to drift down, allowing the load time to shut off. This operation distinguishes the NCP1571 from other parts in its family.
