N80188

Features: ` Integrated Feature Set- Enhanced 8086-2 CPU- Clock Generator- 2 Independent DMA Channels- Programmable Interrupt Controller- 3 Programmable 16-bit Timers- Programmable Memory and Peripheral Chip-Select Logic- Programmable Wait State Generator- Local Bus Controller` Available in 10 MHz ...

product image

N80188 Picture
See larger image
SeekIC No. : 004432617 Detail

N80188: Features: ` Integrated Feature Set- Enhanced 8086-2 CPU- Clock Generator- 2 Independent DMA Channels- Programmable Interrupt Controller- 3 Programmable 16-bit Timers- Programmable Memory and Periphe...

N80188 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
N80188
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

` Integrated Feature Set
- Enhanced 8086-2 CPU
- Clock Generator
- 2 Independent DMA Channels
- Programmable Interrupt Controller
- 3 Programmable 16-bit Timers
- Programmable Memory and Peripheral Chip-Select Logic
- Programmable Wait State Generator
- Local Bus Controller
` Available in 10 MHz and 8 MHz Versions
` High-Performance Processor
- 4 Mbyte/Sec Bus Bandwidth Interface @ 8 MHz (80186)
- 5 Mbyte/Sec Bus Bandwidth Interface @ 10 MHz (80186)
` Direct Addressing Capability to 1 Mbyte of Memory and 64 Kbyte I/O
` Completely Object Code Compatible with All Existing 8086, 8088 Software
- 10 New Instruction Types
` Numerics Coprocessing Capability Through 8087 Interface
` Available in 68 Pin:
- Plastic Leaded Chip Carrier (PLCC)
- Ceramic Pin Grid Array (PGA)
- Ceramic Leadless Chip Carrier (LCC)
` Available in EXPRESS
- Standard Temperature with Burn-In
- Extended Temperature Range (-40 to a85)


Pinout

Connection Diagram


Specifications

Ambient Temperature under Bias ....0 to 70
Storage Temperature ...... .-65 to a150
Voltage on any Pin with
    Respect to Ground.........-1.0V to a7V
Power Dissipation ............... 3W




Description

The following Functional Description describes the base architecture of the 80186. The 80186 is a very high integration 16-bit microprocessor. It combines 15±20 of the most common microprocessor system components onto one chip while providing twice the performance of the standard 8086. The 80186 is object code compatible with the 8086/8088 microprocessors and adds 10 new instruction types to the 8086/8088 instruction set.

For more detailed information on the architecture, please refer to the 80C186XL/80C188XL User's Manual. The 80186 and the 80186XL devices are functionally and register compatible.
