Model 6-13

The Model 6-13 is uniquely designed for use in a broad variety of applications where accurate, reliable, high performance pressure measurement is required.

The Model 6-13 utilizes a micro-machined silicon pressure sensor that is isolated for all media by a 316L stainless steel diaphragm and high performance digital temperature compensation ASIC. This translates into excellent linearity, increased long-term stability & reliability. Micro-machined silicon pressure sensors provide accuracies down to ±0.20% with effectively no hysterisis and a long-term drift of less that 0.15% FSO for one (1) year & proof pressures greater than 3X the rated pressure.

All  Model 6-13  configurations have extremely robust EMI/RFI protection. The Model 6-13 will not shift, drift, or fail in an EMI/RFI environment of greater than 10 volts/meter up to 1.0GHz. The Model 6-13 is hermetically sealed by welding & conforms to NEMA 4 & 4X enclosure requirements.  (Except for vented gage configurations.)

The Model 6-13 can be used in Process Control Systems, Natural Gas Production, Liquid Level Measurement, Gas Compressors, Chemical Processing Systems, Wastewater Treatment, Chemical Processing Systems, Pulp & Paper Processing.

Performance of Model 6-13:Output Signal  4 - 20mADC, Accuracy L, R & H  ±0.35%FSO (BFSL), Zero Offset  ±1.0%FSO, Long-term Stability  ±0.50%FSO/Year, Compensated  Temperature 0°C to 85°C (32°F to 185°F), Temperature Effect   Zero: ±2.0% FSO; Span: ±2.0% FSO.

Operating of Model 6-13 : Input Power  8 - 30 VDC (@ 25mA Max, Insulation Resistance  100 megohms @ 50 VDC, Reverse Polarity  Protected, Proof Pressure  150% of Rated Range, Burst Pressure  200% of Rated Range, Weight  72g (2.5oz).

Environmental of Model 6-13: Max Operating Temperature -40°C to 125°C (-40°F to 257°F) , EMI/RFI  10volts/meter up to 1.0GHz, Wetted Parts  316L SST, Vibration  15 G's, 10-2000Hz, Shock  100 G's for 11ms, Half-sine, Enclosure  NEMA 4 & 4X, Life  100 MM Full Scale Cycles.
