Features: • Bit organization - 4Mb x 8 (byte mode) - 2Mb x 16 (word mode)• Fast access time - Random access:80/25ns(max.)• Page Size - 8 words per page• Current - Operating:40mA - Standby:15uA(max.)• Supply voltage - VCC : 2.7 ~ 3.6V -VCCQ : 2.7 ~ 3.6V• Package ...
MX23L3216: Features: • Bit organization - 4Mb x 8 (byte mode) - 2Mb x 16 (word mode)• Fast access time - Random access:80/25ns(max.)• Page Size - 8 words per page• Current - Operating:4...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
• Bit organization
- 4Mb x 8 (byte mode)
- 2Mb x 16 (word mode)
• Fast access time
- Random access:80/25ns(max.)
• Page Size
- 8 words per page
• Current
- Operating:40mA
- Standby:15uA(max.)
• Supply voltage
- VCC : 2.7 ~ 3.6V
- VCCQ : 2.7 ~ 3.6V
• Package
- 64 ball mini BGA (10.0mm X 13.0mm, ball pitch 1.0mm)
- 56 pin TSOP (14mm x 20mm)
• Temperature
- -25~85°C
Item |
Symbol | Ratings |
Voltage on any Pin Relative to VSS | VIN | -0.3V to 3.9V |
Ambient Operating Temperature | Topr | -25 to 85 |
Storage Temperature | Tstg | -65to 125 |
