MWE6IC9100NR1

Noise Figure :
Bandwidth :
Output Intercept Point :
Operating Supply Voltage :
Supply Current :
Package / Case :
Mounting Style : SMD/SMT
Packaging : Reel
Type : Power Amplifier
Maximum Operating Temperature : + 200 C
Operating Frequency : 869 MHz to 960 MHz


Pinout




Description

The MWE6IC9100NR1 is RF LDMOS wideband integrated power amplifier. It is designed with on-chip matching that makes it usable from 869 to 960 MHz. This multi-stage structure is rated for 26 to 32 Volt operation and covers all typical cellular base station modulations.

The features of MWE6IC9100NR1 can be summarized as:(1)Characterized with Series Equivalent Large-Signal Impedance Parameters and Common Source S-Parameters; (2)On-Chip Matching (50 Ohm Input, DC Blocked); (3)Integrated Quiescent Current Temperature Compensation with Enable/Disable Function ; (4)Integrated ESD Protection; (5)225°C Capable Plastic Package; (6)RoHS Compliant; (7)In Tape and Reel. R1 Suffix = 500 Units per 44 mm, 13 inch Reel.

The absolute maximum ratings of MWE6IC9100NR1 are:(1)Drain-Source Voltage:-0.5V to +66 Vdc; (2)Gate-Source Voltage:-0.5V to +6 Vdc; (3)Storage Temperature Range:-65°C to +150 °C; (4)Case Operating Temperature:150 °C; (5)Operating Junction Temperature:225 °C.

If you want to know more information such as the electrical characteristics about the MWE6IC9100NR1, please download the datasheet in www.seekic.com or www.chinaicmart.com .

Parameters:

Technical/Catalog Information	MWE6IC9100NR1
Vendor	Freescale Semiconductor
Category	Discrete Semiconductor Products
Transistor Type	LDMOS
Voltage - Rated	26V
Current Rating	120mA
Package / Case	TO-270-14
Packaging	Tape & Reel (TR)
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	MWE6IC9100NR1 MWE6IC9100NR1
