MUR3020WT

Product : Ultra Fast Recovery Rectifiers
Reverse Voltage : 200 V
Mounting Style : Through Hole
Forward Continuous Current : 30 A
Max Surge Current : 200 A
Packaging : Tube
Reverse Current IR : 10 uA
Package / Case : TO-247
Configuration : Dual Common Cathode
Recovery Time : 35 ns
Forward Voltage Drop : 1.05 V


Features:

• Ultrafast 35 and 60 Nanosecond Recovery Time
• 175°C Operating Junction Temperature
• Popular TO247 Package
• High Voltage Capability to 600 Volts
• Low Forward Drop
• Low Leakage Specified @ 150°C Case Temperature
• Current Derating Specified @ Both Case and Ambient Temperatures
• Epoxy Meets UL94, VO @ 1/8"
• High Temperature Glass Passivated Junction




Specifications

Rating	Symbol	MUR3020PT	MUR3040PT	MUR3060PT	Unit
Peak Repetitive Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage	VRRM VRWM VR	200	400	600	Volts
Average Rectified Forward Current @ 145°C Total Device	IF(AV)	15 30			Amps
Peak Repetitive Surge Current (Rated VR, Square Wave, 20 kHz, TC = 145°C)	IFRM	30			Amps
Nonrepetitive Peak Surge Current (Surge applied at rated load conditions,halfwave, single phase, 60 Hz)	IFSM	200	150		Amps
Operating Junction and Storage Temperature	TJ,Tstg	65 to +175			°C

Description

Ultrafast Rectifier, 2 x 15 A FRED Pt MUR3020WT
