Product
: Ultra Fast Recovery Rectifiers
Reverse Voltage
: 600 V
Forward Voltage Drop
: 1.25 V
Forward Continuous Current
: 1 A
Packaging
: Reel
Configuration
: Single
Reverse Current IR
: 5 uA
Mounting Style
: Through Hole
Recovery Time
: 50 ns
Max Surge Current
: 35 A
Package / Case
: DO-15
Features: • Ultrafast 25, 50 and 75 Nanosecond Recovery Times
• 175°C Operating Junction Temperature
• Low Forward Voltage
• Low Leakage Current
• High Temperature Glass Passivated Junction
• Reverse Voltage to 600 V
• Pb−Free Packages are Available*Specifications
|
Rating |
SYMBOL |
MUR |
Units |
|
105 |
110 |
115 |
120 |
130 |
140 |
160 |
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage |
VRRM
VRMS
VR |
50 |
100 |
150 |
200 |
300 |
400 |
600 |
V |
Average Rectified Forward Current
(Square Wave Mounting Method #3 Per Note 1) |
IF(AV) |
1.0 @ TA = 130°C |
1.0 @ TA = 120°C |
A |
Nonrepetitive Peak Surge Current
(Surge applied at rated load conditions, halfwave,
single phase, 60 Hz) |
IFSM |
35 |
A |
Operating Junction Temperature and
Storage Temperature |
TJ, Tstg |
-65 to +175 |
°C |
Maximum ratings are those values beyond which device damage can occur. Maximum ratings applied to the device are individual stress limit
values (not normal operating conditions) and are not valid simultaneously. If these limits are exceeded, device functional operation is not implied,
damage may occur and reliability may be affected.
| Part Number
| MUR160 |
| Total Capacitance CT (pF) |
45 |
| Max Av Rectified Current IO (A) |
1 |
| Peak Repetitive Reverse Voltage VRRM (V) |
600 |
| Reverse Recovery Time trr (ns) |
50 |
| Max Peak Forward Surge Current IFSM (A) |
35 |
| Forward Voltage Drop VF (V) |
1.25 |
| Max Reverse Current IR (µA) |
5 |
DescriptionThe MUR160 series of SWITCHMODE power rectifiers are designed for use in switching power supplies, inverters and as free wheeling diodes.
MUR140 and MUR160 datasheet
Parameters: | Technical/Catalog Information | MUR160 |
| Vendor | ON Semiconductor |
| Category | Discrete Semiconductor Products |
| Diode Type | Standard |
| Voltage - DC Reverse (Vr) (Max) | 600V |
| Current - Average Rectified (Io) | 1A |
| Voltage - Forward (Vf) (Max) @ If | 1.25V @ 1A |
| Reverse Recovery Time (trr) | 75ns |
| Current - Reverse Leakage @ Vr | 5A @ 600V |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Mounting Type | Through Hole, Axial |
| Package / Case | DO-41, Axial |
| Packaging | Bulk |
| Capacitance @ Vr, F | - |
| Lead Free Status | Contains Lead |
| RoHS Status | RoHS Non-Compliant |
| Other Names | MUR160
MUR160
MUR160OS ND
MUR160OSND
MUR160OS
|
MUR160 Data Sheet
