MRFIC1808

Designed specifically for application in Pan European digital 1.0 watt DCS1800/PCS1900 handheld radios, the MRFIC1817 is specified for 32 dBm output power with power gain over 27 dB from a 3.6 volt supply. To achieve this superior performance, Motorola's planar GaAs MESFET process is employed. The device is packaged in the PFP16 Power Flat Package which gives excellent thermal and electrical performance through a solderable backside contact while allowing the convenience and cost benefits of reflow soldering.
• Low Current required from Negative Supply 2 mA max
• Guaranteed Stability and Ruggedness
• Order MRFIC1817R2 for Tape and Reel.
R2 Suffix = 1,500 Units per 16 mm, 13 inch Reel.
• Device Marking = M1817
