MRFIC1805

This twostage class AB monolithic GaAs amplifier in a lowcost 16 lead plastic package is designed for output or driver applications in 1.9 GHz PCS handsets and basestations. The design is optimized for 3.0 Volt operation in systems such as Japan's PHS, Europe's DECT and the emerging North American PCS services. With modifications to the simple offchip matching, the device can be used in other applications from 1.5 to 2.5 GHz.
• High Output Capability = 27 dBm Typical Psat21.5 dBm Typical with PHS Format
• High Gain = 21 dB Typical Small Signal, 20 dB at Pout = 22 dBm
• Low Current Drain = 170 mA Typical with PHS Format250 mA Typical with DECT Format
• LowCost, Low Profile Plastic TSSOP Package
• Order MRFIC1805R2 for Tape and Reel.R2 Suffix = 2,500 Units per 16 mm, 13 inch Reel.
• Device Marking = M1805
