MRFIC1504

This MRFIC1504 integrated circuit is intended for GPS receiver applications. The dual conversion design is implemented in Motorola's lowcost highperformance MOSAIC 5E silicon bipolar process and is packaged in a lowcost surface mount LQFP48 package. In addition to the mixers, a VCO, PLL, Crystal Oscillator, A/D converter and a loop filter are integrated onchip. Output IF is nominally 4.1 MHz.
MRFIC1504 features

• 105 dB Typical Conversion Gain
• 2.7 V Operation
• 28 mA Typical Current Consumption
• LowCost, LowProfile Plastic LQFP Package
