MPS2222

Transistor Polarity : NPN
Configuration : Single
Maximum Operating Temperature : + 150 C
Mounting Style : Through Hole
Emitter- Base Voltage VEBO : 5 V
Package / Case : TO-92
Packaging : Bulk
Collector- Emitter Voltage VCEO Max : 30 V
Maximum DC Collector Current : 0.6 A
DC Collector/Base Gain hfe Min : 35 at 0.1 mA at 10 V
Maximum Operating Frequency : 250 MHz (Min)


Specifications

Rating	Symbol	MPS2222	MPS2222A	Unit
CollectorEmitter Voltage	VCEO	30	40	Vdc
CollectorBase Voltage	VCBO	60	75	Vdc
EmitterBase Voltage	VEBO	5.0	6.0	Vdc
Collector Current - Continuous	IC	600		mAdc
Total Device Dissipation @ TA = 25 Derate above 25	PD	625 5.0		mW mW/
Total Device Dissipation @ TC = 25 Derate above 25	PD	1.5 12		Watts mW/
Operating and Storage Junction Temperature Range	TJ, Tstg	55 to +150

Parameters:

Technical/Catalog Information	MPS2222
Vendor	ON Semiconductor
Category	Discrete Semiconductor Products
Transistor Type	NPN
Voltage - Collector Emitter Breakdown (Max)	30V
Current - Collector (Ic) (Max)	600mA
Power - Max	1.5W
DC Current Gain (hFE) (Min) @ Ic, Vce	35 @ 100A, 10mV
Vce Saturation (Max) @ Ib, Ic	400mV @ 15mA, 150mA
Frequency - Transition	250MHz
Current - Collector Cutoff (Max)	-
Mounting Type	Through Hole
Package / Case	TO-92-3, TO-226AA (Straight Leads)
Packaging	Bulk
Drawing Number	*
Lead Free Status	Contains Lead
RoHS Status	RoHS Non-Compliant
Other Names	MPS2222 MPS2222 MPS2222OS ND MPS2222OSND MPS2222OS
