MP2601

Pinout






Description

The MP2601 is a low cost single cell Li-ion battery charger IC suitable for low charge current applications. It features constant current (CC) and constant voltage (CV) charging modes with programmable charge current (50mA?300mA), trickle charge and charge status indication.The MP2601 is enabled with an input supply voltage greater than 3.5V. The charger IC is disabled when unplugged from the AC adaptor. To minimize the charger?s total solution cost, it does not need an external reverse blocking diode, a precision current-sense resistor or a compensation capacitor at the output. MP2601 is available in a 5-pin TSOT23 package.
