MOC8204

Current Transfer Ratio :
Maximum Collector Current :
Maximum Collector Emitter Saturation Voltage : 0.4 V
Minimum Operating Temperature : - 55 C
Maximum Operating Temperature : + 100 C
Maximum Power Dissipation : 250 mW
Packaging : Bulk
Input Type : DC
Isolation Voltage : 5300 Vrms
Package / Case : PDIP-6
Maximum Collector Emitter Voltage : 400 V
Maximum Forward Diode Voltage : 15 V


Application

• Copy Machines
• Interfacing and coupling systems of different potentials and impedances
• Monitor and Detection Circuits
• Solid State Relays


Pinout




Description

The MOC8204 device consists of a gallium arsenide infrared emitting diode optically coupled to a high voltage, silicon, phototransistor detector in a standard 6-pin DIP package. MOC8204 is designed for high voltage applications and is particularly useful in copy machines and solid state relays.
