Product Details

Description

Features:

·Epitaxial Planar Die Construction
·Complementary PNP Type Available (MMST4126)
·Ideal for Medium Power Amplification and Switching
·Ultra-Small Surface Mount Package

Specifications

Characteristic	Symbol	MMST4124	Unit
Collector-Base Voltage	V_CBO	30	V
Collector-Emitter Voltage	V_CEO	25	V
Emitter-Base Voltage	V_EBO	5.0	V
Collector Current - Continuous (Note 1)	I_C	200	mA
Power Dissipation (Note 1)	P_d	200	mW
Thermal Resistance, Junction to Ambient (Note 1)	R_JA	625	K/W
Operating and Storage and Temperature Range	T_j,T_STG	-55 to +150

Notes:
` Valid provided that terminals are kept at ambient temperature.
` Pulse test: Pulse width 300s, duty cycle 2%.

Part Number	MMST4124
Product Type	NPN
V_CEO(V)	25
I_C (A)	0.2
I_CM (A)	-
P_D (W)	0.2
h_FE Min	120
h_FE Max	360
@ I_C (A)	0.002
V_{CE (SAT)} Max (mV)	300
@ I_C (A)	0.05
@ I_B (mA)	5
f_T Min (MHz)	300
R_{CE (SAT)} (m)	-
