MMDF1300

Features: ` Low RDS(on) Provides Higher Efficiency and Extends Battery Life` Logic Level Gate Drive Can be Driven by Logic ICs` Miniature SO8 Surface Mount Package Saves Board Space` Diode Exhibits High Speed, with Soft RecoveryPinoutSpecifications Rating Symbol Value Unit Dra...

product image

MMDF1300 Picture
See larger image
SeekIC No. : 004423743 Detail

MMDF1300: Features: ` Low RDS(on) Provides Higher Efficiency and Extends Battery Life` Logic Level Gate Drive Can be Driven by Logic ICs` Miniature SO8 Surface Mount Package Saves Board Space` Diode Exhibit...

MMDF1300 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
MMDF1300
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

` Low RDS(on) Provides Higher Efficiency and Extends Battery Life
` Logic Level Gate Drive Can be Driven by Logic ICs
` Miniature SO8 Surface Mount Package Saves Board Space
` Diode Exhibits High Speed, with Soft Recovery




Pinout

Connection Diagram


Specifications

Rating

Symbol

Value

Unit

DraintoSource Voltage

VDSS

25

Vdc

GatetoSource Voltage

VGS

± 20

Vdc

Drain Current Continuous
NChannel
PChannel

ID

3.0
2.0

Adc

Drain Current Pulsed
NChannel
PChannel

IDM

9.0
6.0

Apk

Operating and Storage Temperature Range

TJ, Tstg

65 to +150

Total Power Dissipation @ TA = 25

PD

1.8

Watts

Single Pulse DraintoSource Avalanche
Energy Starting TJ = 25
(VDD = 20 Vdc, VGS = 10 Vdc,
IL = 3.0 Apk, L = 25 mH, RG = 25 )

EAS

113

mJ

Thermal Resistance JunctiontoAmbient
(Note 1.)

RqJA

66.3

/W

Maximum Lead Temperature for Soldering
Purposes, 1/8, from Case for 10 sec.

TL

260


` Mounted on 2" square FR4 board (1" sq. 2 oz. Cu 0.06" thick single sided), 10 sec. max.




Description

These MMDF1300 miniature surface mount MOSFETs feature ultra low RDS(on) and true logic level performance. They are capable of withstanding high energy in the avalanche and commutation modes and the draintosource diode has a very low reverse recovery time.

MMDF1300 MiniMOSTM devices are designed for use in low voltage, high speed switching applications where power efficiency is important. Typical applications are dcdc converters, and power management in portable and battery powered products such as computers, printers, cellular and cordless phones. They can also be used for low voltage motor controls in mass storage products such as disk drives and tape drives. The avalanche energy is specified to eliminate the guesswork in designs where inductive loads are switched and offer additional safety margin against unexpected voltage transients.
