MM78C29

· Wide supply voltage range 3V to 15V
· High noise immunity 0.45 V_CC (typ.)
· Low output ON resistance 20X (typ.)

If Military/Aerospace specified devices are required, please contact the National Semiconductor Sales Office/Distributors for availability and specifications.

The MM78C29 is a dual differential line driver that also performs the dual four-input NAND or dual four-input AND function. The absence of a clamp diode to V_CC in the input protection circuitry of the MM78C29 allows a CMOS user to interface systems operating at different voltage levels. Thus, a CMOS digital signal source can operate at a V_CC voltage greater than the V_CC voltage of the MM78C30 line driver. The differential output of the MM78C29 eliminates ground-loop errors.
