MM74C905

· Wide supply voltage range: 3.0V to 15V
· Guaranteed noise margin: 1.0V
· High noise immunity: 0.45 V_CC (typ)
· Low power TTL compatibility: Fan out of 2 driving 74L
· Provision for register extension or truncation
· Operates in START/STOP or continuous conversion mode
· Drive ladder switches directly. For 10 bits or less with 50k/100k R/2R ladder network

The MM74C905 CMOS 12-bit successive approximation register contains all the digit control and storage necessary for successive approximation analog-to-digital conversion.

Because of the unique capability of CMOS to switch to each supply rail without any offset voltage, MM74C905 can also be used in digital systems as the control and storage element in repetitive routines.
