MM5035

· Single 5V power supply
· Internal clocks
· High speed and static operation
· TRI-STATE output buffer
· Recirculate and outut select independent
· TTL compatible

· CRT displays
· Computer peripherals

The MM5035 octal 80-bit shift register is a monolithic MOS integrated circuit utilizing N-channel low threshold enhancement mode and ion-implanted depletion mode devices.

The MM5035 is designed for use in computer display peripherals. All inputs and outputs are TTL compatible.

The clocks and recirculate logic of MM5035 are internal to reduce system component count, and TRI-STATEÉ output buffers provide bus interface. Because of its N-channel characteristics, single 5V power supply operation is required. Simple interface to the NSC CRT DP8350 controller and character generator to incorporate an entire CRT terminal is feasible with the MM5035.

The MM5035 is available in a 22-lead dual-in-line package.
