ML2035IP

The ML2035IP is designed as one kind of serial input programmable sine wave generator device that is intended for telecommunications and modem applications which need low cost and accurate generation of precise test tones, call progress tones, and signaling tones. And this ML2035IP has a VOUT amplitude of ±VCC/2.

Features of the ML2035IP are:(1)Programmable output frequency - DC to 25kHz; (2)Low gain error and total harmonic distortion; (3)3-wire SPI compatible serial microprocessor interface with double buffered data latch; (4)Fully integrated solution - no external components required; (5)Frequency resolution of 1.5 Hz (±0.75Hz) with a 12 MHz clock input; (6)Onboard 3 to 12MHz crystal oscillator; (7)Synchronous or asynchronous data loading capability; (8)Compatible with ML2031 and ML2032 tone detectors and ML2004 logarithmic gain/attenuator.

The absolute maximum ratings of the ML2035IP can be summarized as:(1)Vcc: 6.5 V;(2)Vss: -6.5 V;(3)VOUT: VSS-0.3 V to VCC+0.3 V;(4)Voltage on any other pin: GND-0.3V to VCC+0.3V;(5)Input Current: ±25 mA;(6)Junction Temperature: 150 ºC;(7)Storage Temperature Range: -65 ºC to 150 ºC;(8)Lead Temperature (Soldering, 10 sec): 260 ºC;(9)Thermal Resistance: 110 ºC/W. If you want to know more information about ML2035IP, please download the datasheet in www.seekic.com or www.chinaicmart.com .
