MK2772-01

The MK2772-01 is a low cost, low jitter, high performance VCXO and clock synthesizer for settop boxes. The on-chip Voltage Controlled Crystal Oscillator MK2772-01 accepts a 0 to 3V input voltage to cause the output clocks to vary by ±100 ppm. Using MicroClock's patented VCXO and analog Phase-Locked Loop (PLL) techniques MK2772-01 uses an inexpensive 13.5 MHz crystal input to produce multiple output clocks. All clocks are frequency locked to the 27.00MHz output (and to each other) with zero ppm error. The MK2772 includes a glitch-free multiplexer to switch input sources during operation.

MicroClock MK2772-01 manufactures the largest variety of Set-Top Box and multimedia clock synthesizers for all applications. Consult MicroClock to eliminate VCXOs, crystals and oscillators from your board.
