Series: -
Output: CMOS
Number of Circuits: 1
Differential - Input:Output: No/No
Mounting Type: Surface Mount
Divider/Multiplier: No/No
Package / Case: 16-SOIC (0.154", 3.90mm Width)
Packaging: Tube
Input: Clock
PLL: Yes with Bypass
Voltage - Supply: 3 V ~ 3.6 V
Operating Temperature: -40°C ~ 85°C
Frequency - Max: 133MHz
Supplier Device Package: 16-SOIC
Ratio - Input:Output: 1:8
Manufacturer: IDT, Integrated Device Technology Inc
Type: Zero Delay Buffer
Specifications | Temperature | I |
| Voltage | 3.3 V |
| Package | SOIC 16 |
| Speed | NA |
Description3.3 VOLT ZERO DELAY
The MK2308 is a low phase noise, high-speed PLL based, 8 output, low skew zero delay buffer. Based on IDT's proprietary low jitter Phase Locked Loop (PLL) techniques, MK2308S-1HILF provides eight low skew outputs at speeds up to 133 MHz at 3.3 V. The outputs can be generated from the PLL (for zero delay), or directly from the input (for testing), andMK2308S-1HILF can be set to tri-state mode or to stop at a low level. For normal operation as a zero delay buffer, any output clock is tied to the FBIN pin.
Clock outputs from 10 to 133 MHz
Zero input-output delay
Eight low skew (<200 ps) outputs
Device-to-device skew <700 ps
Full CMOS outputs with 25 mA output drive capability at TTL levels
5 V tolerant FBIN and CLKIN pins
Tri-state mode for board-level testing
Advanced, low power, sub-micron CMOS process
Operating voltage of 3.3 V
Packaged in 16-pin SOIC and TSSOP packages
Available in Pb (lead) free package (SOIC, commercial only)
Industrial and commercial temperature operation
Not recommended for new designs. Use 2308B.
Parameters: | Technical/Catalog Information | MK2308S-1HILF |
| Vendor | IDT, Integrated Device Technology Inc |
| Category | Integrated Circuits (ICs) |
| Type | Zero Delay Buffer |
| Voltage - Supply | 3 V ~ 3.6 V |
| Number of Outputs | 8 |
| Input | Clock |
| Output | CMOS, TTL |
| Frequency-Max | 133MHz |
| Package / Case | 16-SOIC |
| Packaging | Tube |
| Operating Temperature | -40°C ~ 85°C |
| Drawing Number | * |
| Lead Free Status | Lead Free |
| RoHS Status | RoHS Compliant |
| Other Names | MK2308S 1HILF
MK2308S1HILF
|
MK2308S-1HILF Data Sheet
