MJE13007: Transistors Bipolar (BJT) 8A 400V 80W NPN

MJE13007 Data Sheet

Get Latest Price

Part Number:: MJE13007
Mfg:: ON Semiconductor
Supply Ability:: 5000

Price Break

Qty
1~5000

Unit Price
Negotiable

Processing time
15 Days

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/12/22

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

MJE1123 evaluate
Features: • High Gain Limits BaseDrive Losses to only 12% of Circuit Output Current• G...
MJE12007 evaluate
Features: ·With TO-220 package·High voltage·Low saturation voltageApplication·Fluorescent lamp bal...
MJE13001 evaluate
Features: ·HIGH VOLTAGE CAPABILITY ·HIGH SPEED SWITCHING ·WIDE SOAApplication·FLUORESCENT LAMP ·EL...

Product Details

Quick Details

Transistor Polarity :	NPN	Collector- Emitter Voltage VCEO Max :	400 V
Emitter- Base Voltage VEBO :	9 V	Maximum DC Collector Current :	8 A
DC Collector/Base Gain hfe Min :	8	Configuration :	Single
Maximum Operating Frequency :	14 MHz	Maximum Operating Temperature :	+ 150 C
Mounting Style :	Through Hole	Package / Case :	TO-220AB
Packaging :	Tube

Description

Transistor Polarity : NPN
Configuration : Single
Maximum Operating Temperature : + 150 C
Mounting Style : Through Hole
Collector- Emitter Voltage VCEO Max : 400 V
DC Collector/Base Gain hfe Min : 8
Package / Case : TO-220AB
Packaging : Tube
Maximum DC Collector Current : 8 A
Emitter- Base Voltage VEBO : 9 V
Maximum Operating Frequency : 14 MHz

Application

• High Speed Switching
• Suitable for Switching Regulator and Motor Control

Specifications

Symbol	Conditions	Value	Unit
V_CBO	Collector-Emitter Voltage : MJE13006 : MJE13007	600 700	V V
V_CEO	Collector-Emitter Voltage : MJE13006 : MJE13007	300 400	V V
V_EBO	Emitter-Base Voltage	9	V
I_C	Collector Current(DC)	8	A
I_CP	Collector Current (Pulse)	16	A
I_B	Base Current	4	A
P_C	Total Dissipation at T_c= 25	80	W
T_j	Junction Temperature	150
T_shg	Storage Temperature	-65 to150

Parameters:

Technical/Catalog Information	MJE13007
Vendor	ON Semiconductor
Category	Discrete Semiconductor Products
Transistor Type	NPN
Voltage - Collector Emitter Breakdown (Max)	400V
Current - Collector (Ic) (Max)	8A
Power - Max	80W
DC Current Gain (hFE) (Min) @ Ic, Vce	8 @ 2A, 5V
Vce Saturation (Max) @ Ib, Ic	1V @ 400mA, 2A
Frequency - Transition	14MHz
Current - Collector Cutoff (Max)	100A
Mounting Type	Through Hole
Package / Case	TO-220-3 (Straight Leads)
Packaging	Tube
Lead Free Status	Contains Lead
RoHS Status	RoHS Non-Compliant
Other Names	MJE13007 MJE13007 MJE13007OS ND MJE13007OSND MJE13007OS
