MIC5237

The MIC5237 is a general-purpose low-dropout regulator capable of 500mA output current with better than 3% output voltage accuracy. Using Micrel's proprietary Super ßeta PNP™ process with a PNP pass element, these regulators feature of MIC5237 less than 300mV dropout voltage and typically 8mA ground current at full load. Designed for applications that require moderate current over a broad input voltage range, including hand-held and batterypowered devices, the MIC5237 is intended for applications that can tolerate moderate voltage drop at higher current.

Key features of MIC5237 include low ground current to help prolong battery life, reversed-battery protection, current limiting, overtemperature shutdown, and thermally efficient packaging.The MIC5237 is available in fixed output voltages only.For space-critical applications and improved performance,see the MIC5209 and MIC5219. For output current requirements up to 750mA, see the MIC2937.
