MIC4427

The MIC4426/4427/4428 family are highly-reliable dual low-  side MOSFET drivers fabricated on a BiCMOS/DMOS pro- cess for low power consumption and high efficiency. MIC4426/4427/4428 translate TTL or CMOS input logic levels to output voltage levels that swing within 25mV of the positive supply or ground. Comparable bipolar devices are capable of swing- ing only to within 1V of the supply. The MIC4426/7/8 is available in three configurations: dual inverting, dual nonin- verting, and  one inverting plus one noninverting output.

The MIC4426/4427/4428 are pin-compatible replacements for the MIC426/427/428 and MIC1426/1427/1428 with im- proved electrical performance and rugged design (Refer to the Device Replacement lists on the following page). MIC4426/4427/4428 can withstand up to 500mA of reverse current (either polarity) without latching and up to 5V noise spikes (either polarity) on ground pins.

Primarily intended for driving power MOSFETs, MIC4426/7/8 drivers are suitable for driving other loads (capacitive, resis- tive, or inductive) which require low-impedance, high peak current, and fast switching time. Other applications of MIC4426/4427/4428 include driving heavily loaded clock lines, coaxial cables, or piezo- electric transducers. The only load limitation is that total driver power dissipation must not exceed the limits of the package.
