MCP618-I/P

Output Current :
Number of Channels : 1
Common Mode Rejection Ratio (Min) : 80 dB
Packaging : Tube
Shutdown : No
Maximum Operating Temperature : + 85 C
Input Bias Current (Max) : 5000 pA
Mounting Style : Through Hole
Package / Case : PDIP-8
Operating Supply Voltage : 3 V, 5 V
Input Offset Voltage : 0.15 mV at 5.5 V
Slew Rate : 0.08 V/us at 5.5 V


Parameters:

Technical/Catalog Information	MCP618-I/P
Vendor	Microchip Technology
Category	Integrated Circuits (ICs)
Packaging	Tube
Amplifier Type	General Purpose
Number of Circuits	1 - Single
Package / Case	8-DIP (300 mil)
Slew Rate	0.08 V/s
Gain Bandwidth Product	190kHz
Current - Supply	19A
Current - Output/Channel	17mA
Voltage - Supply, Single/Dual (±)	2.3 V ~ 5.5 V
Output Type	Rail-to-Rail
-3db Bandwidth	-
Current - Input Bias	0.015A
Operating Temperature	-40°C ~ 85°C
Voltage - Input Offset	150V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	MCP618 I P MCP618IP
