MCP2515

Features:

• Implements CAN V2.0B at 1 Mb/s:
- 0 - 8 byte length in the data field
- Standard and extended data and remote frames
• Receive buffers, masks and filters:
- Two receive buffers with prioritized message storage
- Six 29-bit filters
- Two 29-bit masks
• Data byte filtering on the first two data bytes (applies to standard data frames)
• Three transmit buffers with prioritizaton and abort features.
• High-Speed SPI™ Interface (10 MHz):
- SPI modes 0,0 and 1,1
• One-shot mode ensures message transmission is attempted only one time
• Clock out pin with programmable prescaler:
- Can be used as a clock source for other device(s)
• Start-of-Frame (SOF) signal is available for monitoring the SOF signal:
- Can be used for time-slot-based protocols and/or bus diagnostics to detect early bus degredation
• Interrupt output pin with selectable enables
• Buffer Full output pins configurable as:
- Interrupt output for each receive buffer
- General purpose output
• Request-to-Send (RTS) input pins individually configurable as:
- Control pins to request transmission for each transmit buffer
- General purpose inputs
• Low power CMOS technology:
- Operates from 2.7V - 5.5V
- 5 mA active current (typical)
- 1 A standby current (typical) (Sleep mode)
• Temperature ranges supported:
- Industrial (I): -40°C to +85°C
- Extended (E): -40°C to +125°C




Specifications

Parameter NameValueVersion Supported2.0B ActiveTx Buffers3Rx Buffers2Masks2Interrupt Output1Filters6Temp. Range (°C)-40 to +125Operating Voltage Range (V)2.7 to 5.5

Parameter Name	Value
Version Supported	2.0B Active
Tx Buffers	3
Rx Buffers	2
Masks	2
Interrupt Output	1
Filters	6
Temp. Range (°C)	-40 to +125
Operating Voltage Range (V)	2.7 to 5.5

Description

The MCP2515 is a second generation stand-alone CAN controller. It is pin and function compatible with the MCP2510 and also includes upgraded features like faster throughput, databyte filtering, and support for time-triggered protocols.

Microchip Technology's MCP2515 is a stand-alone Controller Area Network (CAN) controller that implements the CAN specification, version 2.0B. It is capable of transmitting and receiving both standard and extended data and remote frames. The MCP2515 has two acceptance masks and six acceptance filters that are used to filter out unwanted messages, thereby reducing the host MCUs overhead. The MCP2515 interfaces with MCUs via an industry standard Serial Peripheral Interface (SPI™).
