MCF52259CAG80

32-bit Microcontrollers (MCU) KIRIN3 COLDFIRE V2

product image

MCF52259CAG80 Picture
See larger image
SeekIC No. : 00357744 Detail

MCF52259CAG80: 32-bit Microcontrollers (MCU) KIRIN3 COLDFIRE V2

MCF52259CAG80 Data Sheet

floor Price/Ceiling Price

US $ 4.21~6.71 / Piece | Get Latest Price
Part Number:
MCF52259CAG80
Mfg:
Freescale Semiconductor
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~50
  • 50~100
  • Unit Price
  • $6.71
  • $6.07
  • $5.19
  • $4.21
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Core : ColdFire V2 Processor Series : MCF522x
Data Bus Width : 32 bit Maximum Clock Frequency : 80 MHz
Program Memory Size : 512 KB Data RAM Size : 64 KB
On-Chip ADC : Yes Operating Supply Voltage : 3.3 V to 3.6 V
Package / Case : LQFP-144 Mounting Style : SMD/SMT

Description

Operating Temperature Range :
Data Bus Width : 32 bit
On-Chip ADC : Yes
Mounting Style : SMD/SMT
Maximum Clock Frequency : 80 MHz
Data RAM Size : 64 KB
Program Memory Size : 512 KB
Package / Case : LQFP-144
Core : ColdFire V2
Processor Series : MCF522x
Operating Supply Voltage : 3.3 V to 3.6 V


Parameters:

Technical/Catalog InformationMCF52259CAG80
VendorFreescale Semiconductor
CategoryIntegrated Circuits (ICs)
Program Memory Size512K x 8
RAM Size64K x 8
Number of I /O96
Package / Case144-LQFP
Speed80MHz
Controller SeriesMCF5225x
Oscillator TypeInternal
PackagingTray
Program Memory TypeFLASH
EEPROM Size-
Core ProcessorColdfire V2
Data ConvertersA/D 8x12b
Core Size32-Bit
Operating Temperature-40°C ~ 85°C
ConnectivityCAN, EBI/EMI, Ethernet, I²C, QSPI, UART/USART, USB
PeripheralsDMA, LVD, POR, PWM, WDT
Voltage - Supply (Vcc/Vdd)3 V ~ 3.6 V
Drawing Number*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names MCF52259CAG80
