Product Details

Description



Features:

The primary features of the MCF5202 processor include the following:
• Best-in-Class Code Density
- Requires less memory than fixed length RISC equivalents
- Allows use of slower memory for a given performance level than fixed-length RISCs
- Improves cache effectiveness
• Dynamic Bus Sizing
- 32-, 16-, and 8-bit bus support on the MCF5202 processor
• 2 kbyte On-Chip Unified Cache
- High performance 4-way set associative, non-blocking cache implementation
• Simple Instruction Set Architecture
- Optimized for high-level language constructs
- Requires minimal silicon area to implement processor core
- 16 user-visible 32-bit wide general-purpose registers
- Supervisor / user modes for system protection
- Vector base register to relocate exception-vector table
• Debug Module Including Background Debug and Real Time Debug Support
• Low Interrupt Latency
• Full Static Design Allows Operation Down to DC for Minimizing Power Consumption
• Three-State Pin
• JTAG IEEE 1149.1 Test Interface
• Single Clock Input


Pinout

Connection Diagram


Specifications

RATING
SYMBOL
VALUE
UNIT
Supply voltage
VCC
-0.3 to +7.0
V
Input voltage
Vin
-0.5 to VCC+0.5V
V
Storage temperature range
Tstg
-55 to 150
