MC74LCX258

The MC74LCX258 is a high performance, quad 2input inverting multiplexer with 3state outputs operating from a 2.7 to 3.6V supply. High impedance TTL compatible inputs significantly reduce current loading to input drivers while TTL compatible outputs offer improved switching noise performance. A ^VI specification of 5.5V allows MC74LCX258 inputs to be safely driven from 5V devices.

Four bits of data  of MC74LCX258 from two sources can be selected using the Select input. The four outputs of MC74LCX258 present the selected data in the inverted form. The outputs may be switched to a high impedance state by placing a logic HIGH on the Output Enable (OE) input. Current drive capability is 24mA at the outputs.
