MC68HC05L25

Please deliver the application program to Motorola in one of the following media:
• Macintosh^®1 3 1/2-inch diskette (double-sided 800 K or double-sided high-density 1.4 M)
• MS-DOS^®2 or PC-DOSTM3 3 1/2-inch diskette (double-sided 720 K or double-sided high-density 1.44 M)
• MS-DOS^® or PC-DOSTM 5 1/4-inch diskette (double-sided double-density 360 K or double-sided high-density 1.2 M)
Use positive logic for data and addresses.When submitting the application program on a diskette, clearly label the diskette with the following information:
• Customer name
• Customer part number
• Project or product name
• File name of object code
• Date
• Name of operating system that formatted diskette
• Formatted capacity of diskette

On diskettes, the application program must be in Motorola's S-record format (S1 and S9 records), a character-based object file format generated by M6805 cross assemblers and linkers.

NOTE: Begin the application program at the first user ROM location. Program addresses must correspond exactly to the available on-chip user ROM addresses as shown in the memory map. Write $00 in all non-user ROM locations or leave all non-user ROM locations blank. Refer to the current
