MC54F169

The MC54/74F168 and MC54/74F169 are fully synchronous 4-stage up/ down counters. The F168 is a BCD decade counter; the F169 is a modulo-16 binary counter. MC54/74F168 and MC54/74F169 feature a preset capability for programmable operation, carry lookahead for easy cascading, and a U/ D input to control the direction of counting. All state changes, whether in counting or parallel loading, are initiated by the LOW-to-HIGH transition of the clock.
