MC3363A

Rating

Symbol

Value

Unit

Power Supply Voltage

V_CC

40

Vdc

Comparator Input Voltage Range

V_IR

0.3 to +40

Vdc

Switch Collector Voltage

Vcswitch)

40

Vdc

Switch Emitter Voltage (VPin 1 = 40 V)

VE(switch)

40

Vdc

Switch Collector to Emitter Voltage

VcE(switch)

40

Vdc

Driver Collector Voltage

Vc(driver)

40

Vdc

Driver Collector Current (Note 1)

Ic(driver)

100

mA

Switch Current

IsW

1.5

A

Power Dissipation and Thermal Characteristics
Plastic Package, P, P1 Suffix
TA = 25°C
Thermal Resistance
SOIC Package, D Suffix
TA = 25°C
Thermal Resistance

PD
RJA
PD
RJA

1.25
100
625
160

W
°C/W
W
°C/W

Operating Junction Temperature

TJ

+150

°C

Operating Ambient Temperature Range
MC34063A
MC33063AV
MC33063A

TA

0 to +70
40 to +125
40 to +85

°C

Storage Temperature Range

Tstg

65 to +150

°C
