MC33172DT

Output Current :
Mounting Style : SMD/SMT
Packaging : Reel
Number of Channels : 2
Common Mode Rejection Ratio (Min) : 80 dB
Shutdown : No
Maximum Operating Temperature : + 105 C
Operating Supply Voltage : 5 V, 9 V, 12 V, 15 V, 18 V, 24 V, 28 V
Input Bias Current (Max) : 100 nA
Package / Case : SO N
Input Offset Voltage : 5 mV at 5 V
Slew Rate : 2 V/us at +/- 15 V


Parameters:

Technical/Catalog Information	MC33172DT
Vendor	STMicroelectronics (VA)
Category	Integrated Circuits (ICs)
Packaging	Digi-Reel?
Amplifier Type	General Purpose
Number of Circuits	2 - Dual
Package / Case	8-SOIC (3.9mm Width)
Slew Rate	2 V/s
Gain Bandwidth Product	2.1MHz
Current - Supply	220A
Current - Output/Channel	27mA
Voltage - Supply, Single/Dual (±)	4 V ~ 44 V, ±2 V ~ 22 V
Output Type	-
-3db Bandwidth	-
Current - Input Bias	0.02A
Operating Temperature	-40°C ~ 105°C
Voltage - Input Offset	1000V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	MC33172DT MC33172DT 497 1957 6 ND 49719576ND 497-1957-6
